Control Board IN.YE-5 3KW IN.YE-5-H3.0-AMP-CE-V3 (0610-221107-633)
Control Board IN.YE-5 3KW IN.YE-5-H3.0-AMP-CE-V3 (0610-221107-633)
Control Board IN.YE-5 3KW IN.YE-5-H3.0-AMP-CE-V3 (0610-221107-633)
Control Board IN.YE-5 3KW IN.YE-5-H3.0-AMP-CE-V3 (0610-221107-633)
Control Board IN.YE-5 3KW IN.YE-5-H3.0-AMP-CE-V3 (0610-221107-633)

Gecko IN.YE-5 V3 - 3KW Control Board System (0610-221107-633)

£813.00
£813.00
(-0%)

Inc VAT

Hurry up! only 14 left
Order within the next hours minutes to receive it. Estimated delivery is between and
Control Board IN.YE-5 3KW IN.YE-5-H3.0-AMP-CE-V3 (0610-221107-633)

Gecko IN.YE-5 V3 - 3KW Control Board System (0610-221107-633)

£813.00

Gecko IN.YE-5 V3 - 3KW Control Board System (0610-221107-633)

£813.00
  • The in.ye-5 control system offers a perfect blend of reliability and simplicity, designed to elevate your spa experience. Featuring a 3kW in-flow heater and 5 integrated relays, this system can manage up to five pumps and/or blowers. Notably, dual-speed pumps require 2 relays for optimal function.

    The system includes 5 outputs for various components: Pump 1, Pump 2, Pump 3, Pump 4, Pump 5, Blower, Circ Pump, and Ozone.

    Key Features:

  • For example, a typical setup could include Pump 1 (2-speed using 2 outputs), Pump 2 (1-speed), Blower, and Ozone. If both a circulation and ozone system are used, they must operate on the same voltage and will require an Amp splitter harness.

5 outputs (Note: dual-speed pumps use 2 outputs)
3kW heater with in-flow system
Outputs for Pump 1, Pump 2, Pump 3, Pump 4, Pump 5, Blower, Circ Pump, Ozone
230V outputs for ozonator and auxiliary devices
12V output for projector connection (cable not included)
Easy configuration via keyboard with pre-registered options
Dimensions: 420mm (box width), 498mm (max width with connections), 273mm (height), 126mm (depth)

    Important Note: If using both circulation and ozone systems, ensure they operate on the same voltage and an Amp splitter harness is used.

    Compatible Keyboards:

Main: in.k200, in.k300, in.k336, in.k8, in.k450, in.k500, in.k600, in.k800, in.k1000, in.k1001
Auxiliary: in.k120

Gecko Reference: 0610-221045
Wellis Reference: ACM0756

    Dimension One spa owners should contact us before ordering to ensure system compatibility.

    For further inquiries or assistance, please do not hesitate to reach out.
